                                                                                                                                                                                                               Technical data

Unit structure 1.45″×1(Tweeter) 8″×1(Bass)

Rated power 250W

Peak power 500W

Rated impedance 8Ω

Sensitivity 98dB(1W/1M)

Max sound SPL 119dB

Frequency response 50Hz-20KHz(±3dB)

Physical data  Box structure Positive trapezoidal cabinet

Box material 15MM multilayer birch plywood  Finish Environmentally friendly water-based  Metal treatment High temperature paint handling  Face mask Material Steel net+Spongedustnetwork/netcloth  Lifting way  19×M8 suspension(sings)

Box size 260x455x275mm  Weight   11KG

Product Highlights:

◆High pitch DIF D145-3, high performance loudspeaker, strong magnetism and strong energy sense. It brings strong driving power and wide dynamic range to drive unit, and ensures high and medium frequency penetration, fine and soft.

◆High power long stroke drive unit with low frequency as a special large magnetic steel, DIF D0865-1 bass unit, carrying the magnetic circuit system of the air gap cooling technology (VGC), and keeping good heat dissipation effect in high power and long time use. ◆The designed frequency divider is designed by high order passive frequency divider network to minimize the overlap of the high and low frequency, optimize the performance of the voice part, and use the recoverable PTC protector.

◆The box is made of multi-layer high quality birch splint, and there are a number of stiffeners inside the box, which strengthens the overall stability of the box, and can effectively reduce the resonance of the box when working loudly.  Application scope:

◆The use of music in the high-end nightclubs, senior clubs, high-end bars, multi-function rooms and other places.
